The S-4600 is a portable 3GSDI to HDMI converter. It converts the 3GSDI with its embedded audio to HDMI output, and supports 3GSDI loop through output and SDI embedded audio via 3.5mm earphone output.
The S-4600 is heavy duty housing design, protecting the BNC connectors well, and supplies various screw threads at the bottom, for convenient installing, and future accessories (battery mount, etc.)

Key Features:

Portable 3G/HD/SD-SDI to HDMI Converter
1x 3GSDI input, 1x HDMI output and 1x 3GSDI loop through output
SDI audio output via 3.5mm socket
Embed SDI audio to HDMI output
Power/input/output status indicator
Heavy duty aluminium housing
Bottom screw threads for installing

Input
BNC x 1		3G/HD/SD-SDI input
Output
BNC x 1		3G/HD/SD-SDI loop output
HDMI x 1		Converted HDMI output
3.5mm x 1		SDI audio output
Video Format
SDI	SMPTE-425M	1080p (60 / 59.94 / 50)
	SMPTE-274M	1080i (60 / 59.94 / 50)
		1080p (30 / 29.97 / 25 / 24 / 23.98)
	SMPTE-RP211	1080psf (30 / 29.97 / 25 / 24 / 23.98)
	SMPTE-296M	720p (60 / 59.94 / 50)
	SMPTE-125M	480i (59.94)
	ITU-R BT.656	576i (50)
HDMI		1080p (60/ 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98)
		1080i (60 / 59.94 / 50)
		720p (60 / 59.94 / 50)
		480i / 576i
Audio		48KHz Sync
General
Power		≤3W
Working Voltage		DC 6-18V
Working Environment		Temperature: 0°C-+70°C, Humidity:10%-90%
Dimensions		98x84x29 mm

Converter

Price

Collections

Swit S-4600 SDI to HDMI Converter

Lumantek ez-SH SDI to HDMI Converter

Lumantek ez-SHV+ SDI to HDMI Converter with Display

Lumantek EZ-HSV+ HDMI to SDI Converter with Display and Scaler

Lumantek ez-MD+HDMI/SDI Converter with Audio Mux/Demux
